What technical parameters are required for the selection of orifice flow meters?

1， Fluid type: Different flow meters should be selected for clear and mixed liquids, clean gases, and mixed gases. 2. Flow range: The fluid flow range should be moderate and not exceed the range of the flowmeter. 3. Pipeline size: For smaller pipeline sizes, rotor, turbine, and orifice flow meters are generally used. For larger pipeline diameters, orifice socks and ultrasonic flow meters are commonly used instead. Some materials of pipelines are not suitable for electromagnetic and ultrasonic applications.

2. How to choose high-quality orifice flow meters and the selection method for orifice flow meters with large spring flow rates?

What is a high-quality flowmeter? It means that the flowmeter has high accuracy, long service life, and timely after-sales service.; To choose a flow sock gauge, the first step is to determine the medium being measured, and then the type of flow meter can be determined. After that, it is necessary to file and screen the factorys data. This is the only way to purchase high-quality flow meters. 3. Wireless input type liquid level sensor. 4. Working principle of orifice flow meter. An orifice flow meter is a device that calculates gas flow by measuring pressure difference. Its core principle is based on energy conservation and flow continuity in fluid mechanics. Here is a detailed explanation:

1. Working principle: When gas flows through an orifice plate, due to the sudden reduction in the cross-sectional area of the orifice plate, the gas flow velocity increases significantly at the orifice, while the pressure decreases. According to the Bernoulli equation, the kinetic energy

and static pressure energy of a fluid are converted into each other, and an increase in flow velocity leads to a decrease in static pressure, thereby forming a pressure difference (Δ P) between the upstream (high-pressure side) and downstream (low-pressure side) of the orifice plate. The relationship between flow rate and pressure difference: Under stable flow conditions, the gas flow rate (qv) is proportional to the square root of the pressure difference (Δ P), that is: qv: gas volume flow rate (m3/min) K: orifice plate coefficient (determined by orifice plate geometry, gas properties, etc., calibrated at the factory) Δ h: water column pressure difference measured by U-tube (mm), multiplied by density ratio 13.6 if using mercury column. By measuring the pressure difference Δ h and combining it with the known K value, the gas flow rate can be calculated.

2. Structure Composition: The orifice flowmeter consists of the following core components: orifice plate: a circular thin plate with a precisely sized circular hole in the center, which is a key component for generating pressure difference.

. Pressure nozzle: located upstream and downstream of the orifice plate, used to connect a differential pressure gauge (such as a U-shaped tube) and measure the pressure difference Δ h. Steel pipe and flange: form a gas circulation pipeline, and fix the orifice plate through the flange to ensure sealing. Auxiliary components: including sealing rings, connecting bolts, negative pressure gauges (monitoring pipeline pressure), etc.

III. Specifications and Selection of Orifice Plate Diameter Selection: The size of the orifice plate is determined based on the estimated gas drainage volume and the range of water column pres
