1. What is the general compressed air flow rate in a factory? There is no fixed standard for the compressed air flow rate in a general factory, usually around 200L/min (for low-power air compressors), but it needs to be dynamically calculated based on the number of pneumatic tools and operating conditions. 1. Core factors affecting flow rate: ① Air compressor power: For low-power models (such as 7.5kW), the typical flow rate is about 200L/min before the age of the child, which can meet the needs of a single pneumatic tool. ② Tool concurrency: When multiple pneumatic tools are running simultaneously, it is necessary to stack the gas consumption of each tool and reserve 20% redundancy. ③ Work pressure: The pressure parameter (unit MPa) directly affects the flow calculation results, and the commonly used pressure range is 0.4-0.8MPa
2. Practical methods for flow calculation: ① Formula for maximum gas consumption of the cylinder: $Q_ {max}=0.047D ^ 2S (p+0.1)/0.1 \ times1/t $Example: D=5cm cylinder, S=10cm stroke, p=0.5MPa, t=2 seconds, Qmax is about 294L/min ② Formula for average gas consumption: Double acting cylinder: $Q_ {average}=2 \ times (s times n \ times q) $Parameter description: stroke length s (cm) x number of cycles per minute n x one-way gas consumption q (L/min) cm), q value can be obtained by consulting the pneumatic tool parameter table. ③ Quick estimation principle: The average air consumption of each standard cylinder (cylinder diameter 50mm) at a pressure of 0.5MPa is about 8-12 L/min.
2. What are the flow regulation methods for metering pumps?
3. Calculation method for energy consumption of air compressor
The energy consumption calculation of air compressor mainly involv
1. Calculate the input power consumption based on the parameters on the motor nameplate. Taking a conventional single-stage air compressor (132kW model, flow rate 43.88m3/min, working pressure 3Bar) as an example, the following parameters need to be paid attention to: motor rated power (P): 132kW (rated output power or shaft power), motor efficiency (η): 94.7% (taking Huada motor as an example), power factor (COS φ): 0.892, service factor (S.F)
1.2 (some manufacturers use 1.25) 1. The sentence is: The formula for the nominal rated input power of the motor (without considering the service factor and full load) is: P1=rated output power of the motor (P) ÷ motor efficiency (η). Substitute the data into the formula: P1=132kW ÷ 94.7% ≈ 139.39kW. The formula for the nominal rated input power (considering the service factor and full load) is: P2=(rated output power of the main motor (P) ÷ main motor efficiency (η)) × (service factor (S.F) -0.05) (theoretical calculation requires a 5% margin, cannot be fully calculated). Substitute the data into the formula: P2=(132kW ÷ 94.7%) × (1.2-0.05) ≈ 165.3kW. 3. Nominal specific power (considering the service factor and full load). The formula is: PB1=nominal rated input power (P2) ÷ flow rate. Substitute the data: PB1=165.3kW ÷ 43.88m3/min ≈ 3.77kW/(m3/min) 4 Additional calculations for air-cooled machines (taking into account fan power consumption) If the machine is an air-cooled Kai key grip, the fan input power needs to be added: Fengzhuqing fan motor rated power: 4.5kW fan efficiency: 85% fan input power (PF): PF=fan rated power ÷ fan efficiency PF=4.5kW ÷ 85% ≈ 5.29kW
