Kral Fuel Flow Meter Sizing: True Supply and Return Differential Balancing Logs for Large Ship Diesel

Quick Answer

Quick Answer: For large ship diesel engines, size KRAL fuel flow meters as a matched pair on the supply and return lines. Use actual flow, temperature, and viscosity for each line, not only the net fuel consumption. Record supply flow, return flow, differential flow, fuel temperature, pressure, and totalizer values in the balancing log every 4 hours.

Why True Differential Measurement Matters on Large Ship Diesel Engines

Large marine diesel engines return much more fuel to the settling tank than they burn. A 6,000 kW propulsion engine may receive 12,000 kg/h from the fuel oil booster module and return 9,000 kg/h. The net consumption is only 3,000 kg/h. If you use one flow meter on the supply line only, the meter error can be larger than the net fuel burn. We have seen this error on vessels in Singapore and Piraeus. Two KRAL positive displacement flow meters installed on the supply and return lines solve this problem. The true differential value is supply flow minus return flow calculated in the flow computer or control system. The differential value is the actual fuel consumption for the main engine.

Sizing a KRAL Fuel Flow Meter for the Supply Line

Start with the fuel oil booster module flow at normal full load. Check the flow in kg/h and convert the flow to volume flow in l/h at the fuel temperature. For heavy fuel oil at 120 °C with density near 0.98 kg/l, a 12,000 kg/h supply flow is about 12,245 l/h. Select a KRAL positive displacement meter with a measuring range that covers 20 to 120 percent of that volume flow. For 8,000 to 15,000 kg/h at 15 to 25 cSt viscosity, a KRAL BEM series meter with DN25 or DN40 body often fits. Because the supply meter sees the full booster flow, do not select the meter based on net consumption only.

Sizing the Return Line Meter

The return flow is often 3 to 5 times the net consumption. Do not downsize the return meter because the net flow looks small. For a 12,000 kg/h supply flow and a 9,000 kg/h return flow, use the same meter model and the same DN as the supply line if possible. A matched pair reduces differential error from temperature drift and calibration. Check pressure drop at maximum return flow. Keep pressure drop below 0.3 bar on the return line if the booster pressure margin is small. Install the return meter before the back pressure valve where the fuel remains liquid and free of vapor.

Balancing Logs That Ship Engineers Actually Use

A practical fuel balancing log should include the date, time, engine load, supply flow in kg/h, return flow in kg/h, differential flow in kg/h, fuel temperature at the supply meter, fuel temperature at the return meter, pressure at the supply meter, density input, supply totalizer reading, return totalizer reading, and the difference between the two totalizers. Record every 4 hours during steady steaming. Most engineers skip the density and temperature fields. Then a fuel grade change or a 15 °C temperature shift changes the mass flow correction and the differential value drifts. The log becomes a comparison of volumes only and hides a real fuel measurement error.

Temperature and Viscosity Correction in the Balancing Log

Fuel temperature changes density and viscosity. For heavy fuel oil, a 20 °C temperature drop can change density by about 0.013 kg/l. On a 3,000 kg/h net consumption, that density shift equals a mass flow change of

Common Installation Mistakes on Marine Fuel Systems

One mistake is using different meter sizes on supply and return lines. That creates a mismatch at low evening load. Another mistake is installing the return meter directly before an open tank inlet. The fuel can flash or release vapor when back pressure drops. Install a strainer upstream of each meter and an air eliminator at the high point. Positive displacement meters need clean fuel. Keep the meter full of liquid at all times. For heavy fuel oil lines, heat tracing and insulation are important. A cold spot near the meter can increase viscosity and change the meter curve. For hazardous area installation on tankers, select ATEX Zone 1 certified meters.

Signal Wiring and Totalizing for Differential Measurement

Use pulse outputs from both KRAL fuel flow meters. A 4-20 mA HART output is acceptable for monitoring but pulse output gives better totalized difference values. Wire both pulse outputs into the same PLC or flow computer. Use the same pulse scaling and the same sample window. Some ships use a dedicated fuel consumption monitor that subtracts the return pulses from the supply pulses. In practice, the pulse difference is cleaner than subtracting two analog signals. Check the K-factor on each meter calibration certificate and enter the exact value. But do not use the default K-factor only.

What is true supply and return differential flow on a ship?

True differential flow is the supply flow minus the return flow measured at the same time. On a large ship diesel engine, this value gives the net fuel consumption of the engine.

How do I size a KRAL fuel flow meter for heavy fuel oil?

Use the actual flow at the fuel temperature and viscosity for each line. Convert kg/h to l/h using the fuel density at the meter. Select a meter with a measuring range that covers 20 to 120 percent of that volume flow.

Can I use two different meter sizes for supply and return lines?

You can, but we do not recommend it. A matched pair with the same model and DN reduces differential error. If the return flow is much lower than the supply flow, check the minimum flow range of the return meter before selecting a smaller size.

What should be recorded in a marine fuel balancing log?

Record date, time, engine load, supply flow, return flow, differential flow, fuel temperature, fuel pressure, density, and both totalizer readings. Log every 4 hours during steady operation.

What fuel temperature and viscosity should I use for sizing?

Use the normal fuel oil temperature at the engine inlet, often 120 to 150 °C for heavy fuel oil. Viscosity at that temperature is often 10 to 25 cSt. For marine diesel oil, use 40 °C and 2 to 11 cSt.

Contact and Sizing Support

Send your pipe size in DN, fuel type, viscosity in cSt, temperature in °C, pressure in bar, supply flow range in kg/h, and return flow range in kg/h. Contact Silver Automation Instruments at Tel: +86-25-68650347, Whatsapp: +86-25-52155837, WeChat: +86 15365082610. We help you size a matched KRAL fuel flow meter set for large ship diesel engines.
