What are the corresponding sizes of various specifications of vortex flowmeters? The size specifications of vortex flowmeters may vary depending on different manufacturers and models. Generally speaking, nominal diameters ranging from DN15 to DN600 or even larger are covered. For vortex flowmeters with smaller diameters such as DN15-DN50, the overall length is relatively short, usually around 150-300mm, and the height and width are also relatively small. Li Huai is suitable for smaller pipeline installation spaces, and its flange size meets the corresponding national standards, making it easy to connect with pipelines. The length of the circular DN80-DN200 vortex flowmeter is approximately in the range of 300-600mm. As the diameter increases, the length, height, and width will also increase accordingly to ensure measurement stability and accuracy. The flange size is also increased according to the standard to match larger diameter pipelines. When the nominal diameter reaches DN250-DN600 and above, the size further increases, and the length may be around 600-1500mm. The overall shape is larger to meet the needs of high flow measurement, and the installation flange and other connecting components are also compatible with large-diameter pipelines. In practical applications, when selecting a vortex flowmeter, it is necessary to determine the most suitable size specifications based on specific factors such as pipeline diameter, installation environment, and process requirements, and refer to the detailed product specification manual provided by the manufacturer to ensure smooth installation and use.

2. What are the sizes corresponding to different diameters of vortex flowmeters?

Vortex flowmeters of differ

ent diameters correspond to different sizes, and products produced by different manufacturers may have differences in specific dimensions. Taking the common DN25 caliber as an example, its length is generally around 150mm and the outer diameter is about 32mm. The DN50 caliber vortex flow meter has a length of about 200mm and an outer diameter of about 57mm. For DN80 caliber, the length is usually around 250mm and the outer diameter is about 89mm. For DN100 caliber, the length is about 300mm and the outer diameter is about 108mm. When the caliber increases to DN150, the length is approximately 400mm and the outer diameter is about 159mm. The length of a DN200 caliber vortex flowmeter is generally around 500mm and the outer diameter is about 219mm. These dimensional data are only approximate ranges. In practical applications, when selecting a vortex flowmeter, accurate dimensional information should be obtained based on the product manual and specification parameter table provided by the specific manufacturer to ensure correct installation and use.

3. What are the specific size values of the flowmeter before and after installation? There is no fixed standard for the size values of flow meters before and after installation, and they may vary depending on the type of flow meter, pipeline system, and specific application scenario. Generally speaking, before installation, the appropriate flow meter should be selected based on the actual inner diameter of the pipeline. The inner diameter size of the pipeline is the key basic data, and different pipe diameters correspond to different specifications of flow meters. For example, the common DN50 (nominal diameter of 50 millimeters) pipeline needs to be equipped with a flow

2. What are the sizes corresponding to different diameters of vortex flowmeters?
