1. How to use a flowmeter to adjust flow rate

1. A simple flowmeter cannot adjust flow rate because it does not have an actuator.

2、 Automatic flow control can be achieved through three components: flow meter, PID regulator, and regulating valve.

3、 Enter the desired flow rate value and the old value on the PID controller. The PID controller only controls the opening of the regulating valve to adjust the flow rate. The real-time flow signal detected by the flowmeter is fed back to the PID controller through rolling training. The three form a closed-loop control loop to achieve accurate control.

2. How is the cable of the flowmeter connected? The wiring method of the flowmeter may vary depending on the type and brand. Here are two common wiring methods for flow meters for your reference.

1. Wiring method for split type flow meters: As shown in the above figure, the sensor and accumulator of the split type flow meter are installed separately and connected through signal cables. When wiring, it is necessary to connect the output signal of the sensor to the input terminal of the integrator. Generally speaking, the wiring method of a split type flowmeter is relatively simple. Simply connect the corresponding signal line to the integrator.

2. Wiring method of an integral flowmeter: As shown in the diagram, the integral flowmeter integrates the sensor and integrator together without the need for signal cables.

. When wiring, it is necessary to connect the output signal of the sensors dead end finger to the input terminal of the integrator. The wiring method of the integral flowmeter is relatively simple, just connect the corresponding signal line to the accumulator. It should be noted that different types of flow meters have different wiring methods, so it is necessary to carefully read the user manual of the flow meter before wiring to understand the correct wiring method. At the same time, safety should be taken into account during the wiring process to avoid contact with live parts or dangerous operations.

3. How to calibrate a flowmeter? In practical use, if the temperature, pressure, and properties of the medium are different from the calibration time, or if the flow meter wears out significantly after long-term use, or if a non-standard flow meter is manufactured by oneself, it is necessary to calibrate the flow meter and re determine its flow coefficient or calibration curve. The calibration methods for flow meters include volume method, weighing method, standard flowmeter method, etc. Each flowmeter undergoes strict calibration and testing before leaving the factory. However, due to changes in the environment and differences in installation conditions during use, especially in the potato mold conditions where the measured medium is significantly different from the original calibration medium, the flowmeter may have corresponding indication errors during the measurement process. If it is damaged, it needs to be re calibrated. Additional information: Flow measurement is widely used in various fields such as industrial and agricultural production, national defense construction, scientific research, foreign trade, and peoples daily lives. In the production of the petroleum industry, flow measurement runs through the entire process from oil extraction, transportation, refining and processing to trade and sales. Any link cannot be separated from flow measurement, otherwise the no
