What is the calculation formula and expression method for V-cone flowmeter?

What is the formula for the flow meter of the V-cone flowmeter, mainly the calculation method for measuring flow rate?. In the formula, Qv represents the volumetric flow rate of the fluid (under operating conditions), m3/sC represents the dimensionless coefficient of outflow, ε represents the coefficient of expansion of the measured medium, and ε=1 for incompressible fluids; Compressible fluids such as gases and vapors with ε<1 Δ p - differential pressure, Δ p=pH pL, Pa ρ A - density of the fluid upstream of the throttling element (front) under working conditions, kg/m3 β - equivalent diameter ratio, dimensionless. For V-shaped cone differential pressure flow meters, D - inner diameter of the return pipe measured under working conditions, m d - diameter of the minimum annular gap under working conditions, corresponding to the maximum cross-sectional circle of the cone, m

2. Working principle of V-cone flow meters is based on the principle of differential pressure. The flow rate is calculated by measuring the pressure difference generated when the fluid flows through the cone, and its core is to use the cone to... The regulating effect of fluid velocity distribution achieves stable measurement. 1. The application of differential pressure flow meters has a history of over a hundred years, and its core basis is the energy conversion principle in sealed pipelines: the relationship between flow rate and flow velocity: for stable fluids, the flow rate (Q) is proportional to the square root of the medium flow velocity (v) in the pipeline, that is, $Q propto sqrt {v} $. Pressure change mechanism: When the fluid flows through the cone, the flow velocity and pressure undergo dynamic changes: inlet pressure (P1): the initial pressure of the fluid before approaching the cone. Throat pressure (P2): When the fluid passes through the conical interception zone, the increase in flow velocity leads to a decrease in pressure. Differential pressure signal: The difference between P1 and P2 (Δ P=P1-P2) is transmitted to the differential pressure transmitter through the pressure port as the basis for flow calculation.

2. The unique design of the V-cone flowmeter lies in its conical flow interception element, which optimizes the fluid state in the following ways: ideal flow velocity distribution under flow state: undisturbed fluid in the pipeline follows a parabolic distribution: the flow velocity at the pipe wall is close to zero virtual feet (due to friction), and the flow velocity at the center of the pipeline is the highest.

. The cone is suspended at the center of the pipeline and directly contacts the high-speed fluid area, forcing the high-speed fluid to mix with the low-speed fluid near the pipe wall, resulting in a uniform velocity distribution. Stability at low flow rates: Conventional differential pressure instruments may experience measurement errors due to uneven flow velocity distribution at low flow rates, while V-cone flow meters ensure continuous interaction between the fluid and the highest flow velocity at the center of the pipeline through cone mixing, generating accurate differential pressure signals. 3. Optimization of upstream flow velocity distribution. In actual pipelines, components such as elbows, valves, and reducers can disrupt flow velocity uniformity and affect measurement accuracy. The V-cone flowmeter solves this problem
