1. Model List of Tiankang Split type Ultrasonic Heat Meter
Currently, there is no clear official model list of Tiankang Split type Bench resistant Ultrasonic Heat Meter in public information. The following are relevant models and characteristics of split type ultrasonic heat meters with similar functions and structures to this type of product for reference. For accurate models, it is recommended to consult Tiankang official for information. 1. TDS-100 Series - Application Scenarios: Online Measurement of Heating Pipeline Network - Product Composition: Adding a Temperature Sensor to a Fixed Ultrasonic Flow Meter for Heat Measurement - Host Type: Wall Mounted, Explosion proof, Disk Mounted, Modular - Sensor Type: External, Changzaolv Plug in, Pipe Section - Core Parameters: Meets EN1434 standard, Measurement Cycle 500ms, Supports 85-220VAC or Isolated 24VDC/8-30VDC Power Supply 2. TUC-2000S Series - Product Positioning: Fixed Split Ultrasonic Cold/Heat Meter - Fine opening Foolish Type and Corresponding Form: - TUC-2000SB: Wall Mounted - TUC-2000SS: Disk Mounted - TUC-2000SD: Explosion proof 3. DDM - TF1500R- Application scenario: Online metering of heating pipeline network - Host type: wall mounted standard type, wall mounted explosion-proof type, disk mounted type, local display type - Sensor type: external attachment type, insertion type, pipe section type - Core parameters: measurement accuracy of 2% -3%, measurement cycle of 500ms
2. TDS-100P portable ultrasonic flowmeter Chinese manual: [1]
TDS-100P portable ultrasonic flowmeter Chinese manual Core content is as follows:
1. Product Overview TDS-100P portable ultrasonic flowmeter is a high-precision, non-contact flow measurement instrume
2. Instructions for use Installation steps Selection of measurement points: Avoid interference areas such as pipeline bends and valves, and ensure that the length of the upstream and downstream straight pipe sections meets the requirements (usually more than 10 times the diameter of the pipeline).
. Clamp sensor: Install the sensor perpendicular to the pipeline axis, adjust the spacing according to the K value indicated in the manual, and fill the gap with coupling agent to enhance signal transmission. Connect the host: Connect the sensor to the host through a dedicated cable, automatically recognize the sensor type and enter the measurement interface after booting up. Operation process parameter setting: Enter parameters such as pipeline material, outer diameter, wall thickness, etc., select fluid type (such as water, oil, etc.) and temperature compensation mode. Start measurement: After pressing the "Start" button, the host automatically emits ultrasonic signals and calculates the flow rate, which is displayed on the scr
