Is there any gold in the components of the AF-E400 flowmeter? Currently, there is no publicly available information indicating that the components of the AF-E400 flowmeter contain gold. AF-E400 belongs to the field of electromagnetic flow meters and is mainly used in public utilities and industrial automation scenarios. It is suitable for flow measurement of conductive liquid media. Its public parameters show that the shell is made of 2mm thick cast stainless steel, and there is no mention of components made of gold materials. 2. Types and Differences of Flowmeters
Flowmeters are mainly divided into volumetric, velocity, differential pressure, mass, and other categories based on their measurement principles. The core differences lie in their working principles, applicable dielectric properties, and accuracy characteristics.
. 1. Working principle of volumetric flowmeter: The fluid is divided into fixed volume units by mechanical measuring elements, and the flow rate is calculated by counting the number of units. Representative types: elliptical gear, waist wheel, scraper flowmeter. Applicable medium: high viscosity liquids (such as oils, chemical reagents). Accuracy: ± 0.2%~± 0.5% (higher). Characteristics: Sensitive to changes in fluid viscosity, filters need to be installed to prevent jamming. Working principle of velocity flowmeter: flow rate is derived by measuring fluid velocity, usually requiring matching pipeline size data. Representative type: • Electromagnetic flowmeter: Based on Faradays law of electromagnetic induction, it measures conductive liquids (such as water, acidic and alkaline solutions) with an accuracy of ± 0.2%~± 0.5% and no pressure loss. Turbine flowmeter: By driving the tur
3. Differential pressure flowmeter working principle: Based on the Bernoulli equation, the flow rate is calculated by measuring the pressure difference before and after the throttling element. Representative types: orifice plate, V-cone, Venturi tube. Applicable media: steam, gas, liquid (widely used). Accuracy: ± 1%~± 2% (greatly affected by installation conditions). Characteristics: The structure is simple but there is permanent pressure loss, requiring a differential pressure transmitter and a pressure pipe. 4. Working principle of the mass flowmeter: It directly measures the mass flow rate of the fluid without density compensation. Representative type: Coriolis flowmeter: utilizing the Coriolis force balance effect generated by the flow of slag in a vibrating tube, with an accuracy of ± 0.1%~± 0.2%, capable of simultaneously measuring density and temperature. • Thermal mass flowmeter: measures gas mass flow rate (such as compressed air, combustion gas) through heating elements and temperature sensors, with an accuracy of ± 1%~± 2.5%
5. Other special types • Vortex flowmeter: measures steam, gas or liquid flow rate by detecting vortex shedding frequency, with an accuracy of ± 1%, and is resistant to high temperature and high pressure. Rotary flowmeter: based on the change of float position to measur
