Gas liquid two-phase flowmeter

『Gas liquid two-phase flowmeter』Related information(clamp on meter|electromagnetic meter|venturi meterrotameter|orifice meter|ultrasonic flow meter|mass flow meter|coriolis mass flow meter|coriolis flow meter|magnetic flow meter|magmeter flow meter|magflow flow meter|mag meter flow meter|electromagnetic flow meter|vortex flow meter|turbine flow meter|thermal mass flow meter|thermal flow meter|rotameter flow meter)

1. Yangpai Technology Bi directional Mixed Phase Flow Meter SPMF-P-T

Yangpai Technology Bi directional Mixed Phase Flow Meter SPMF-P-T is a high-precision and high stability flow metering device. Here is a detailed analysis of the product:

1. Product Overview: Yangpai Technologys bidirectional mixed phase flow meter SPMF-P-T, also known as a channel flow meter, adopts Yangpai Technologys latest patented measurement technology. This flowmeter uses a channel type (spindle) as a throttling device, which can achieve continuous real-time, high-precision, and highly stable measurement/monitoring of multiple parameters in the mass flow rate of mixed phase flow, such as gas content/liquid content, gas flow rate, liquid flow rate, and total mass flow rate. Through the same source and phase separation measurement technology, this flowmeter can accurately identify the fluid pressure loss factors at various pressures and temperatures, ensuring that the measurement of gas flow is not affected by manifold, flow state, pressure, and temperature changes. Therefore, it is particularly suitable for bidirectional metering of gas storage wells and injection production wells in the same pipeline.

2. Product Features: Automatic determination of medium flow direction: This flowmeter has an integrated design, simple structure, and can automatically determine the flow direction of the medium without manual intervention.

. Adaptability to large-span fluctuations: Through light quantum absorption and multi parameter sensing system, this flowmeter can adapt to large-span fluctuations in pressure and flow rate, meeting the needs of gas injection. Online mixed phase metering: This flowmeter can achieve online mixed phase me
Gas liquid two-phase flowmeter
tering without the need for fluid separation, greatly improving metering efficiency and accuracy. Self calibration of light quantum absorption coefficient: The light quantum absorption coefficient of this flowmeter can self calibrate the gas medium composition, without being affected by the composition changes of the gas after it contains liquid, thus achieving accurate measurement of gas-liquid medium phase fraction. Horizontal installation: This flowmeter can be installed horizontally without the need for front and rear straight pipe sections, and can be directly replaced with pipelines, making installation simple and fast. Dealing with special working conditions: This flowmeter can handle special working conditions such as bidirectional metering and has a wide range of applications.

3. Performance indicators Communication method: RS485

5. Large key RJ4

5. IoT card 4G (can be customized according to customers).

. Specification size: DN80~DN300. Power supply mode: DC24V/AC220V (can be customized according to customers). Design pressure: ≤ 42MPa. Rated power:<10W. Medium temperature: -40 ℃~100 ℃. Explosion proof rating: Ex db IIB T6 Gb. Environmental temperature: -40 ℃~+85 ℃. Protection level: IP66. Environmental humidity: (0~95)% RH. Installation method: Vertical/horizontal installation. Scope of application: LVF: (0~100)%; Mode switching includes dry gas single-phase/wet gas two-phase/oil gas water three-phase. Equipment weight: (60-680) kg. Flow range: Refer to the "Comparison Table of Flow Range of Multiphase Flow Meter". Flange standard: HG20592-20615/ASME B16.5/API 6A/Boost 33259 (customized according to customer). Material: 30

4, 31

6, 316L, Hastelloy, Nickel based alloy (can be c
